PRIME 24000 BTU HEAT/COLD 17 SEER R-32 220V

PRIME 24000 BTU HEAT/COLD 17 SEER R-32 220V

$766.32 USD
$766.32 USD
Sale Sold out
Shipping calculated at checkout.

The PRIME 24000 BTU Mini Split System delivers year-round comfort for rooms up to 1,200 sq. ft. Engineered with a high-efficiency 17 SEER2 inverter compressor and eco-friendly R-32 refrigerant, this ductless mini split air conditioner and heat pump provides powerful cooling and heating while lowering energy costs. Operates on 208/230V power for reliable performance in residential and commercial applications.

Built for durability in coastal and humid climates, it features Gold Shield Anticorrosive Coating on the condenser coils. Built-in Wi-Fi control lets you manage your system remotely from your phone. AHRI Certified, ETL Listed, and A2L Safety Rated for verified performance you can trust.

Features

  • Inverter Compressor — variable-speed for quiet, efficient operation
  • AHRI Certified — independently verified capacity and efficiency ratings
  • Pre-charged with R-32 Refrigerant — lower GWP, higher energy efficiency
  • Wi-Fi Control — adjust temperature and modes from your smartphone
  • Room Temperature Remote Sensor — reads ambient temp at the remote for precise comfort
  • Turbo Function — rapid cooling and heating when you need it fast
  • Gold Shield Anticorrosive Coating — extended lifespan in coastal and humid environments
  • Sleep Mode, Auto Restart & Timer — set-and-forget convenience
  • AutoClean — self-drying function prevents mold and odor buildup
  • Temperature & Humidity Control — maintains ideal indoor conditions

Documentation

Technical Specifications

General
Model 24,000 BTU/h
Power Supply 208/230V~ / 60 Hz / 1Ph
Refrigerant R-32
Cooling Performance
Rated Cooling Capacity (95°F/35°C) 23,000 BTU/h
Cooling Capacity Range 5,120 – 24,500 BTU/h
EER (95°F/35°C) 9.5 BTU/W·h
SEER2 17 BTU/W·h
Heating Performance
Rated Heating Capacity (47°F/8.3°C) 22,400 BTU/h
Rated Heating Capacity (17°F/−8.3°C) 13,500 BTU/h
Heating Capacity Range 5,120 – 24,500 BTU/h
HSPF2 (Region IV) 9.5 BTU/W·h
HSPF2 (Region V) 8.5 BTU/W·h
COP2 (47°F/8.3°C) 3.3 W/W
Max Heating Capacity (5°F/−15°C) 12,000 BTU/h
COP2 (5°F/−15°C) 1.8 W/W
Electrical
Rated Input – Cooling 2,365 W
Rated Input – Heating 1,900 W
Rated Current – Cooling 12 A
Rated Current – Heating 13 A
Installation
Connecting Pipe – Gas 1/2"
Connecting Pipe – Liquid 1/4"
Dimensions & Weight
Indoor Unit (W × D × H) 39.76 × 12.40 × 8.66 in
Outdoor Unit (W × D × H) 33.97 × 13.74 × 23.70 in
Indoor Unit Weight 26.5 lbs
Outdoor Unit Weight 65.0 lbs
