PG 24000 BTU HEAT/COLD 17 SEER2 R-32 220V

PG 24000 BTU HEAT/COLD 17 SEER2 R-32 220V

$687.01 USD
$687.01 USD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.

The PG 24000 BTU Mini Split System delivers year-round comfort for rooms up to 1,200 sq. ft. Engineered with a high-efficiency 17 SEER inverter compressor and eco-friendly R-32 refrigerant, this ductless mini split air conditioner and heat pump provides powerful cooling and heating while lowering energy costs. Operates on 208/230V power for reliable performance in residential and commercial applications.

Built for durability in coastal and humid climates, it features Gold Shield Anticorrosive Coating on the condenser coils. Built-in Wi-Fi control lets you manage your system remotely from your phone. AHRI Certified, ETL Listed, and A2L Safety Rated for verified performance you can trust.

Features

  • Inverter Compressor — variable-speed for quiet, efficient operation
  • AHRI Certified — independently verified capacity and efficiency ratings
  • Pre-charged with R-32 Refrigerant — lower GWP, higher energy efficiency
  • Wi-Fi Control — adjust temperature and modes from your smartphone
  • Room Temperature Remote Sensor — reads ambient temp at the remote for precise comfort
  • Turbo Function — rapid cooling and heating when you need it fast
  • Gold Shield Anticorrosive Coating — extended lifespan in coastal and humid environments
  • Sleep Mode, Auto Restart & Timer — set-and-forget convenience
  • AutoClean — self-drying function prevents mold and odor buildup
  • Temperature & Humidity Control — maintains ideal indoor conditions

Documentation

Technical Specifications

General
Model 24,000 BTU/h
Power Supply 208/230V~ / 60 Hz / 1Ph
Refrigerant R-32
Cooling Performance
Rated Cooling Capacity 24,000 BTU/h
Cooling Capacity Range 2,700 – 25,000 BTU/h
Rated Input – Cooling 2,450 W (range: 300 – 3,000 W)
Rated Current – Cooling 11.5 A (range: 1.4 – 14.35 A)
EER 2.83
SEER 17
Heating Performance
Rated Heating Capacity 24,000 BTU/h
Heating Capacity Range 2,700 – 25,000 BTU/h
Rated Input – Heating 2,450 W (range: 300 – 3,000 W)
Rated Current – Heating 11.5 A (range: 1.4 – 14.35 A)
COP 2.86
Electrical
Max Input Consumption 3,000 W
Max Current 14.35 A
Installation
Connecting Pipe – Liquid Φ6 (1/4")
Connecting Pipe – Gas Φ15.88 (5/8")
Max Refrigerant Pipe Length 15 m (49.2 ft)
Max Height Difference 10 m (32.8 ft)
Indoor Unit
Dimensions (W × H × D) 1,030 × 334 × 232 mm (40.6 × 13.1 × 9.1 in)
Net Weight 13.5 kg (29.8 lbs)
Airflow (Hi/Mi/Lo) 1,050 / 950 / 800 m³/h
Noise Level (Hi/Mi/Lo) 50 / 47 / 45 dB(A)
Outdoor Unit
Dimensions (W × H × D) 860 × 378 × 597 mm (33.9 × 14.9 × 23.5 in)
Net Weight 35 kg (77.2 lbs)
Noise Level 57 dB(A)
Refrigerant
Type R-32
Charge 1,055 g
Design Pressure 4.5 MPa
Operating Range
Cooling 16°C to 43°C (61°F to 109°F)
Heating 16°C to 48°C (61°F to 118°F)
